Speed Bend 10100 x 1500 TN
Hover to Zoom

Sell Speed Bend 10100 x 1500 TN

Specification of Speed Bend 10100 x 1500 TN

Speed ​​Bend 10100 x 1500 TN


  • Mono block, welded steel frame rigid against high deflection and pull with ST44 A1 material.
  • 4 axis (Y1, Y2, X and R)
  • The rear measuring system with the X + R axis is driven by an AC servo with color graphics
  • The standard graphics controller can be selected from: ER90 3D color graphics screen controller with offline CYBELEC MOD EVA 12S 3D color graphics software with PC 1200 offline software.
  • Delem DA-66T 2D with color graphics
  • HOERBIGER servo hydraulic system
  • CNC controlled anti-deflection system.
  • The electrical panel with a cooling Machine Tool system is designed to meet CE standards and consists of automation and electrical equipment under the SIEMENS brand.
  • Hardened and grinded standard sectioned top and 4V-Die bottom tools (835mm section)
  • Easy to clamp tool holds the system with top and bottom tools.
  • User-friendly ergonomic control panel, pendant
  • Rear security guard (category-4)
  • The front side closes with a safety switch.
  • Sync Y1 + Y2 axis provided by a linear encoder with a tolerance of 0.01
  • Foot pedal in accordance with CE regulations.
  • Front support arm with T slot and mm / inch rulers
  • Throat dept 410 mm.

Untuk keterangan lebih lanjut, silahkan download PDF ini :
